AD8671ARMZ-R2
数据手册.pdfADI(亚德诺)
主动器件
精密，极低噪声，低输入偏置电流运算放大器 Precision, Very Low Noise, Low Input Bias Current Operational Amplifiers
GENERAL DESCRIPTION
The AD8671/AD8672/AD8674 are veryhigh precision amplifiers featuring very low noise, very low offset voltage and drift, low input bias current, 10 MHz bandwidth, and low power consumption. Outputs are stable with capacitive loads of over 1000 pF. Supply current is less than 3 mA per amplifier at 30 V.
FEATURES
Very low noise: 2.8 nV/√Hz, 77 nV p-p
Wide bandwidth: 10 MHz
Low input bias current: 12 nA max
Low offset voltage: 75 μV max
High open-loop gain: 120 dB min
Low supply current: 3 mA per amplifier
Dual-supply operation: ±5 V to ±15 V
Unity-gain stable
No phase reversal
