ADV7604BBCZ-5

12位， 170 MHz的视频和图形数字化仪，四路HDMI接收器 12-Bit, 170 MHz, Video and Graphics Digitizer with Quad HDMI Receiver

GENERAL DESCRIPTION

The ADV7604 is a high quality, single chip, multiformat video decoder, graphics digitizer with an integrated 4:1 multiplexed High-Definition Multimedia Interface HDMI® receiver. The ADV7604 contains one main component processor CP that processes YPrPb and RGB component formats, including RGB graphics. The CP also processes the video signals from the HDMI receiver. The ADV7604 can operate in quad HDMI and analog input mode, thus providing simultaneous HDMI and analog video sync processing. This allows for fast switching between HDMI and the ADCs.
