AD6649BCPZRL7

中频分集接收机中频采样频率为400 MHz的 IF Diversity Receiver IF sampling frequencies to 400 MHz

RF IC IF 分集接收器 CDMA2000，GSM/EDGE - 采样率达 250MSPS 64-LFCSP-VQ（9x9）

得捷:
IC IF RCVR 14BIT 250MSPS 64LFCSP

立创商城:
AD6649BCPZRL7

艾睿:
IF Diversity Receiver 64-Pin LFCSP EP T/R

安富利:
The AD6649 is a mixed-signal intermediate frequency IF receiver consisting of dual 14-bit, 250 MSPS ADCs and a wideband digital downconverter DDC. The AD6649 is designed to support communications applications, where low cost, small size, wide bandwidth, and versatility are desired.The dual ADC cores feature a multistage, differential pipelined architecture with integrated output error correction logic. Each ADC features wide bandwidth inputs supporting a variety of user-selectable input ranges. An integrated voltage reference eases design considerations. A duty cycle stabilizer is provided to compensate for variations in the ADC clock duty cycle, allowing the converters to maintain excellent performance.

Chip1Stop:
IF Diversity Receiver 64-Pin LFCSP EP T/R

Verical:
IF Diversity Receiver 64-Pin LFCSP EP T/R

罗切斯特:
IF Diversity Receiver 64-Pin LFCSP EP T/R
