ADG751ARMZ-REEL
数据手册.pdf模拟开关 IC 65dB 150 Ohm 300MHz CMOS RF/Video SPST
视频 开关 IC 1 通道 8-MSOP
得捷:
IC VIDEO SWITCH SPST 8MSOP
立创商城:
ADG751ARMZ-REEL
贸泽:
模拟开关 IC 65dB 150 Ohm 300MHz CMOS RF/Video SPST
艾睿:
Analog Switch Single SPST 8-Pin MSOP T/R
安富利:
The ADG751 is a low voltage SPST single pole, single throw switch. It is constructed in a T-switch configuration, which results in excellent Off Isolation while maintaining good frequency response in the ON condition.High off isolation and wide signal bandwidth make this part suitable for switching RF and video signals. Low power consumption and operating supply range of +1.8 V to +5.5 V make it ideal for battery powered, portable instruments.The ADG751 is designed on a submicron process that provides low power dissipation yet gives high switching speed and low on resistance. This part is a fully bidirectional switch and can handle signals up to and including the supply rails.The ADG751 is available in 6-lead SOT-23 and 8-lead µSOIC packages.
Chip1Stop:
Analog Switch Single SPST 8-Pin MSOP T/R
罗切斯特:
Analog Switch Single SPST 8-Pin MSOP T/R
