ERJ-6BWFR022V

PANASONIC ELECTRONIC COMPONENTS  ERJ-6BWFR022V  厚膜电阻, 0.022Ω, 1%, 0805, 整卷

22 mOhms ±1% 0.5W，1/2W 芯片 0805（2012 公制） 汽车级 AEC-Q200，电流检测 厚膜

得捷:
RES 0.022 OHM 1% 1/2W 0805

艾睿:
Use this ERJ-6BWFR022V fixed single surface-mount resistor from Panasonic to obtain a visually clean layout. This dependable part has a power rating of 0.5 1/2 W. This product has a resistance value of 22m Ohm. It is also complete with current sensing technology. Its temperature coefficient is ±200 ppm/°C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has a tolerance of 1%. This device is made with thick film technology. This product is 2 mm long, 0.6 mm tall and 1.25 mm deep. This part has an operating temperature of -55 to 155 °C.

立创商城:
22mΩ ±1% 500mW

Verical:
Res Thick Film 0805 0.022 Ohm 1% 0.5W1/2W 0ppm/C to 200ppm/C Pad SMD Automotive T/R

Newark:
# PANASONIC ELECTRONIC COMPONENTS  ERJ-6BWFR022V  SMD Current Sense Resistor, 0.022 ohm, 500 mW, 0805 [2012 Metric], ± 1%, ERJ6B Series

MASTER:
Res Thick Film 0805 0.022 Ohm 1% 0.5W1/2W 0ppm/°C to 200ppm/°C Pad SMD Automotive T/R

Online Components:
Res Thick Film 0805 0.022 Ohm 1% 0.5W1/2W ±200ppm/°C Molded SMD Automotive T/R

Electro Sonic:
Res Thick Film 0805 0.022 Ohm 1% 0.5W1/2W 0ppm/°C to 200ppm/°C Pad SMD Automotive T/R
