100141-1

Z-Pack 125 位置 直 5 排 插头 B 型 2 mm 硬公制 连接器

Z-PACK/B MALE HDR 125P, 2MM HM

Product Highlights

Connector

Connector Type = Type B, 25 Column

Plug

Interface Type = 2mm HM

Contact Type = ACTION PIN Post, Signal

得捷:
CONN HEADER 125POS 2MM PRESS-FIT

立创商城:
PIN：125 间距2mm 公 直插

艾睿:
The speed and size of this hard metric 100141-1 backplane connector from TE Connectivity provide a significant advantage for linking multiple small scale devices and operations. This PL connector&s;s 125 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. This is a 5-row connector. It has a maximum voltage rating of 500 VAC. It has a plug type gender. Its pitch is 2 mm. This device has a maximum current rating of 1.5 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. 100141-1 is housed in gray polybutylene terephthalate. It uses the press fit termination method. This product is 49.9 mm long, 13.45 mm tall and 15.4 mm deep. This backplane connector has an operating temperature of -55 to 125 °C.

Allied Electronics:
Connectors; Hard Metric; Z-PK/B MALE HDR 125P

安富利:
Conn Hard Metric PL 125 POS 2mm Press Fit ST Thru-Hole

富昌:
Z-Pack 125 位置 直 5 排 插头 B 型 2 mm 硬公制 连接器

Chip1Stop:
Conn Hard Metric PL 125 POS 2mm Press Fit ST Thru-Hole

Verical:
Conn Hard Metric PL 125 POS 2mm Press Fit ST Thru-Hole Automotive Tube

Newark:
# AMP - TE CONNECTIVITY  100141-1  Connector, Z-PACK Series, Hard Metric HM, 125 Contacts, Header, 2 mm, Press Fit

MASTER:
MALE ASSEMBLY, Z-PACK 2mm HM, TYPE B

Powell:
2mm Hard Metric PCB Mount Connectors Z-PACK 2mm HM

Online Components:
Z-PACK/B MALE HDR 125P, 2MM HM

Electro Sonic:
Z-PACK/B MALE HDR 125P, 2MM HM

Win Source:
CONN HEADER 125POS 2MM PRESS-FIT / 125 Position Header, Male Pins Connector 0.079" 2.00mm Through Hole
