0022102141

2.54毫米（ .100 ）间距KK®线对板头，单列，立式，电路14 ，PA聚酰胺尼龙，金（Au ）镀层 2.54mm .100 Pitch KK® Wire-to-Board Header, Single Row, Vertical, 14 Circuits, PA Polyamide Nylon, Gold Au Plating

Connector Header Through Hole 14 position 0.100" 2.54mm

得捷:
CONN HEADER VERT 14POS 2.54MM

艾睿:
Safety is an important concern when designing electronic devices. Molex&s;s unshrouded 0022102141 header connector helps protect your equipment from accidental shortages. This HDR connector&s;s 14 contacts that are made out of brass and plated with gold over nickel. This is a 1-row connector. It has a straight body orientation. Its pitch is 2.54 mm. It has a header type gender. It has a maximum voltage rating of 250 V. This device has a maximum current rating of 4 A/contact. It uses the solder termination method. 0022102141 is housed in white nylon. This product is 35.31 mm long, 10.79 mm tall and 2.34 mm deep. This connector has an operating temperature of -40 to 80 °C.
