TLP4227GF

Relay SSR 50mA 1.3V DC-IN 0.15A 350V 4Pin PDIP

* TLP4227G: 4 pin DIP DIP4, 1 channel type 1 form B * Peak off-state voltage: 350 V min * Trigger LED current: 3 mA max * On-state current: 150 mA max * On-state resistance: 25 Ω max * Isolation voltage: 2500 Vrms min * UL recognized: UL1577 File No. E67349

得捷:
SSR RELAY SPST-NC 150MA 0-350V

艾睿:
Solid State Relay 50mA 1.3V DC-IN 0.15A 350V 4-Pin PDIP Magazine

安富利:
Relay SSR 50mA 1.3V DC-IN 0.15A 350V 4-Pin PDIP

Chip1Stop:
Relay SSR 50mA 1.3V DC-IN 0.15A 350V 4-Pin PDIP

Verical:
Relay SSR 50mA 1.3V DC-IN 0.15A 350V 4-Pin PDIP Magazine
