SRU1028-150Y

SRU1028 系列磁性屏蔽线绕扼流圈薄型屏蔽结构 高电流额定值。 非常适合于高频率。 应用：直流/直流转换器，EMI 滤波器。 ### Bourns 非标准表面安装电感器（扼流圈）

SRU1028 系列磁性屏蔽线绕扼流圈

薄型屏蔽结构

高电流额定值。

非常适合于高频率。

应用：直流/直流转换器，EMI 滤波器。

得捷:
FIXED IND 15UH 2A 69 MOHM SMD

立创商城:
15uH ±30% 2A 69mΩ

欧时:
Bourns SRU1028 系列 屏蔽 铁氧体芯材 15 μH 绕线贴片电感器 SRU1028-150Y, ±30%容差, 2A Idc Q:26

艾睿:
This power SRU1028-150Y surface mount inductor from Bourns is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This product is 10.3 mm long, 3.1 mm tall and 10.3 mm deep. This device is made with wirewound technology. It has an inductance of 15u H. This SMD inductor has a maximum DC current of 2 A with a maximum resistance of 69m Ohm. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 22M Hz.

Allied Electronics:
Inductor, SMT Power/Shielded; 15uH; 30% Tol; SRF Min 22MHz; DCR 0.069 Ohm; 26 Qref

安富利:
Ind Power Shielded Wirewound 15uH 30% 100KHz 26Q-Factor Ferrite 2A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 15uH 30% 100KHz 26Q-Factor Ferrite 2A 69mOhm DCR T/R

Verical:
Inductor Power Shielded Wirewound 15uH 30% 100KHz 26Q-Factor Ferrite 2A 0.069Ohm DCR T/R

Newark:
# BOURNS  SRU1028-150Y  Surface Mount Power Inductor, SRU1028 Series, 15 µH, 2 A, 2 A, Shielded, 0.069 ohm

MASTER:
Inductor Power Shielded Wirewound 15uH 30% 100KHz 26Q-Factor Ferrite 2A 69mOhm DCR T/R

Online Components:
Inductor Power Shielded Wirewound 15uH 30% 100KHz 26Q-Factor Ferrite 2A 69mOhm DCR T/R

Electro Sonic:
Inductor Power Shielded Wirewound 15uH 30% 100KHz 26Q-Factor Ferrite 2A 69mOhm DCR T/R

Win Source:
FIXED IND 15UH 2A 69 MOHM SMD / 15 µH Shielded Drum Core, Wirewound Inductor 2 A 69mOhm Nonstandard
