PCF1A271MCL1GS

CF 系列 Ø 10 x 8 mm 10 V 270 uF 有机导电聚合物 电容

铝聚合物器 径向，Can - SMD 20 毫欧 105°C 时为 2000 小时

得捷:
CAP ALUM POLY 270UF 20% 10V SMD

立创商城:
270uF ±20% 10V

艾睿:
Thanks to Nichicon and their PCF1A271MCL1GS conductive polymer aluminum solid capacitor, you can feel rest assured that your integrated circuit will be protected from sudden changes in the load. It can withstand a voltage of 10 VDC. It has 2 terminals. It has a tolerance of 20%. This conductive polymer aluminum solid capacitor has an operating temperature range of -55 °C to 105 °C. Its leakage current is 540@2Min μA. This product is 8 mm tall with a diameter of 10 mm.

安富利:
Cap Aluminum 270uF 10V 20% 10 X 8mm SMD 0.02 Ohm 3600mA 2000 hr 105°C T/R

Chip1Stop:
Cap Aluminum 270uF 10V 20% 10 X 8mm SMD 0.02 Ohm 3600mA 2000h 105 C T/R

Verical:
Cap Aluminum Polymer 270uF 10VDC 20% 10 X 8mm SMD 0.02 Ohm 3600mA 2000h 105C Automotive T/R
