OPA445BM
TI(德州仪器)
主动器件
TEXAS INSTRUMENTS OPA445BM 运算放大器, 单路, 2 MHz, 1个放大器, 15 V/µs, ± 10V 至 ± 45V, TO-99, 8 引脚
The is a high voltage FET-input monolithic Operational Amplifier capable of operation from power supplies up to ±45V and output currents of 15mA. It is useful in a wide variety of applications requiring high output voltage or large common-mode voltage swings. The OPA445"s high slew rate provides wide power bandwidth response, which is often required for high-voltage applications. FET input circuitry allows the use of high-impedance feedback networks, thus minimizing their output loading effects. Laser trimming of the input circuitry yields low input offset voltage and drift.
- .
- 10pA Low input bias current
- .
- 10µV/°C Offset drift
- .
- 95dB Typical CMRR
- .
- Green product and no Sb/Br
